Model SB3502 is a 3.5" x 3.5" residential weight hinge made from extruded solid brass with a stainless steel pin. It features square corners, a 5-knuckle design, and a removable pin for easy door removal. Built to the Timely template, it is reversible for both left- and right-hand doors. Supplied with Phillips flat-head wood screws for quick installation.
• Size: 3.5" x 3.5"
• Finish Options:
• US3 – Polished Brass
• US3A – Unlacquered Brass
• US5 – Antique Brass
• US10B – Oil-Rubbed Bronze
• US15 – Satin Nickel
• US15A – Antique Nickel
• US26 – Polished Chrome
• US26D – Satin Chrome
• Corners: Square
• Pin Type: Removable Pin
• Bearing Type: Residential Weight, 5 Knuckles
• Template: Timely
• Material: Extruded solid brass with stainless steel pin
• Gauge of Metal: 0.102"
• Pin Diameter: 0.236"
• Screws Included: #10 x 1" wood screws
• Quantity per Inner Box: 2
• Quantity per Case: 80
• Average Weight per Case: 43 lbs
• Model: SB3502
3.5" x 3.5" Solid Brass Hinge, Square Corner, 2 Ball Bearings
Inches: 3-1/2" x 3-1/2"
Millimeter: 88.9 x 88.9
